Passing Data Between Blocks

This is the most common thing you do when building a flow: a step ran, it produced something, and a step further down needs it. A lookup returned a customer and the email step needs their address; a calculation produced a total and a condition has to test it.

The mechanics are quick to learn and are covered in Expression Editor: open the editor on the field that needs a value, find the earlier block's result, drill to the field you want, and apply it. This page is about the parts that trip people up once they start building - what is actually readable from where, and how to keep a flow legible as it grows.

Decide what a block leaves behind

Every action block has two settings that decide whether its result is available afterwards, and what it is called. Both are switches you control.

Reference Result Data As publishes the result under an alias - the name you look for when a later step needs it. It is on by default, and the alias defaults to the block's name with "Result" on the end, so a step named Get Order publishes Get Order Result and a later field reads Get Order Result → orderId.

That default is the reason naming blocks pays off immediately. A field read as Look Up Customer Result → email explains itself; one read as Untitled Block 3 Result → email does not. Change the alias in that field whenever a clearer name helps.

Assign to a Variable stores the result in a Data Bucket variable as well. It is off by default. Reach for it when the value has to outlive the block - to survive a loop, or to be read under a name of your own choosing. See Holding Values in Variables.

A block's configuration panel: Reference Result Data As is ticked and holds the alias HTTP Request Result, with Assign to a Variable unticked below it.

Turn the alias off when nothing needs it

Because the alias is a switch, you can clear it. Do that for blocks whose result no later step reads - a notification that was sent, a record that was written and never referred to again.

The gain is not performance, it is legibility. Every published alias joins the list of values later steps can pick from, so that list grows as the flow does. Switching off the ones nothing reads keeps it to values worth picking.

What a later step can and cannot read

Most of the time everything upstream is available: a block can read the result of any block that ran before it, not only the one wired directly into it. The wires decide what runs next, not who may read what.

Three cases break that expectation, and they are worth knowing before they surprise you:

  • Inside a loop, a result belongs to the current pass. A block's result inside a List Iterator or Repeat is scoped to that pass - each pass overwrites it, a later pass cannot read an earlier pass's result, and nothing produced inside the loop is readable after it ends. To carry a value between passes or out of the loop, put it in a variable declared outside the loop. See Holding Values in Variables.
  • A branch that did not run produced nothing. If a step reads a result from a path the run never took, there is nothing to resolve. Read values that every path produces, or set one variable on each branch so the step after the merge has a single name to read.
  • A result's fields may not be listed yet. Blocks that only learn their result's shape by running - an HTTP Request, an AI Agent - show nothing to pick until they have run once. Run the block in Test Mode and the fields appear.
  • Expression Editor - the dialog itself: picking references, drilling into fields, combining values, and the Live Preview
  • Blocks - what a result is and how a block publishes one
  • Holding Values in Variables - when a value needs a name of its own that outlives the block
  • Reshaping Data - when the value you need has to be derived rather than read
